FMD3200BB

MSRP: $13,995.00

Black Box Electronics Chart Display and Information System (ECDIS) w/o Display

Chart TypeRaster or Vector

Display SizeSupplied Separately

Display TypeSupplied Separately

Power Usage115 or 230 VAC

View Support/Tech Info Find a Dealer

All prices shown are in USD. Prices are valid in US and Canada only.

Home Products FMD3200BB

Direct connect sensors

Navigation sensors can be directly interfaced with the ECDIS processor’s 8 serial I/O ports. In order to integrate onboard sensors into the navigation network, the sensor adapter may be interfaced with the switching hub HUB100, from which distribution of the sensor data throughout the network is possible. Alternatively, multiple sensor adapters may be interfaced via Ethernet to integrate onboard sensors for use in the shipboard network. The FMD3200 can interface with existing FAR21x7/FAR28x7 series Radar for Radar overlay, target track info, route and waypoint exchange via Ethernet.

FMD3200 Chart Engine

Cutting-edge chart engine and intuitive controls

The FMD3200 utilizes cutting edge chart-drawing engine that delivers instantaneous chart redraw with seamless zooming and panning, making operation stress-free. Moreover, its operation philosophy is based upon the same familiar logic as the control scheme of a PC mouse, and all operations can be controlled with the use of trackball of the control unit by means of left-clicking, right-clicking and using a thumbwheel. A full QWERTY style keyboard is available in the ECDIS control unit for easy route, event and waypoint naming.

FMD3200 Status Bar

Simplified operation with the Status Bar and InstantAccess Bar

The FMD3200 provides the operator with quick access to the tasks and functions to be performed in the midst of vessel operation. This new ECDIS employs two new, intelligently arranged Graphic User Interface elements: Status Bar and InstantAccess Bar, that deliver task-based operation scheme to give the operator direct access to necessary operational procedure. The Status Bar at the top of the screen provides operating status, including modes of operation and presentation. The InstantAccess Bar on the left edge of the screen provides quick access to functions available in each of the ECDIS operating modes. The contents of the InstantAccess Bar change according to the operating modes selected on the Status Bar. This combination of the Status Bar and InstantAccess Bar covers virtually the entire operation, providing the operator with quick and easy access to the tasks to be performed. Subsequently, the need for delving into intricate menu trees to reach necessary tasks has become a thing of the past. The FMD3200 has streamlined the navigation monitoring procedure, reducing the risk of confusion and erroneous operation as well as enhancing situation awareness.

Direct connect sensors

Control of the FMD3005 is made easy with the ECDIS Control Unit RCU024, featuring a full-QWERTY keyboard, or the Trackball Control Unit RCU026. All functions of the ECDIS can be accessed by using the trackball, scroll wheel, and left/right clicking.

  • Product Consists Of
  • Cables
  • Marine Monitors
  • Miscellaneous Accessories
  • Manuals

Product Consists Of

Product Consists Of

$12,045.00

PROCESSOR UNIT FMD3200

$1,950.00
Keyboard/Trackball Control Unit w/5 meter Cable

Cables

Cables

$9.00
TTYCSLA-1 ONE PAIR LOW SMOKE, PRICED PER METER
$325.00
CBL 6TPSH-XH12X2 10M RCU026
$665.00
CBL 6TPSH-XH12X2 20M RCU026
$1,055.00
CBL 6TPSH-XH12X2 30M RCU026
$295.00
CABLE DVI-BNCX5-L2000 FMD-VDR

Marine Monitors

Marine Monitors

$7,495.00

27" Widescreen Monitor

$4,495.00
24" LCD Monitor
$5,995.00
27" LCD Monitor

Miscellaneous Accessories

Miscellaneous Accessories

$1,650.00

SENSOR ADAPTER SERIAL FMD3200

$1,125.00
SENSOR ADAPTER ANALOG
$995.00
SENSOR ADAPTER DIGITAL-IN
$1,075.00
SENSOR ADAPTER DIGITAL-OUT
$2,850.00
Interswitch/Hub
$3,270.00
RADAR CONNECTION BOX FOR ECDIS
$195.00
24S103930 CABLE ASSY 5M
$0.00
ECDIS CPU TRAINING DVD CBT*
$300.00
ECDIS CPU TRAINING LICENSE CBT*
$1,795.00
TRKBL CONT UNIT W/5M FMD3200
$195.00
DSUB9P-X2-A-L 5M CBL ASSY
$2,700.00
Universal Pedestal for FAR22x8BB, FAR3x00 and FAR2xx7
$2,000.00
Table Top Mount for FAR Series Radars and FMD Series ECDIS

Manuals

Manuals

$50.00
OP MANUAL FMD3200/3300/BB
$40.00
INST MANUAL FMD3200/3300/BB

Recommended Additions

  • MU190HD

    $6,195.00

    19" Color LCD Monitor without bracket

    Details
  • FAR2228BB

    Call For Price
    25 kW Transmitter, 96 NM Black Box Radar, less Performance Monitor, Antenna, and Cable
    Details
  • FAR3220BB

    Call For Price
    FAR3000 Series Black Box Chart Radar with Performance Monitor, 25kw X-Band, 96 NM
    Details
  • FA170

    $3,795.00

    Class A AIS Transponder w/ 4.3" Color LCD Display

    Details
  • VR7000

    Call For Price

    Voyage Data Recorder

    Details
View All

FMD3200 and FMD3300 Brochure

For more information, including dimensions and product specifications, download the brochure.
