NAVPILOT 500

No Longer Available

MSRP: $3,795.00

Navigational Autopilot with Heading Sensor

Display Size4.6 inches

Display TypeMono LCD

Power Usage12 VDC or 24 VDC

Prices and Specifications Subject to Change Without Notice.

View Support/Tech Info Find a Dealer

All prices shown are in USD. Prices are valid in US and Canada only.

Home Products NAVPILOT 500
  • Product Consists Of
  • Related Products
  • Autopilot Pumps
  • Miscellaneous Accessories
  • Manuals

Product Consists Of

Product Consists Of

PG500R
$995.00

Rate Compensated Heading Sensor

FAP5001
$1,295.00
Waterproof 4.6" LCD Display/Control Unit with 10 Meter Pigtail Interface/Power Cable, White Weather Cover and Standard Flush-Mounting Kit (Control Unit Mounting Bracket Optional)
FAP5002
$1,305.00

Processor Unit

FAP6112
$375.00

Rudder Reference Unit for NAVpilot

Related Products

Related Products

FAP6011B
$895.00

Single Din Control Unit - NavPilot Series

FAP5021
$895.00
Hand Held Control Unit
FAP5001A
$1,295.00

Optional 4.6" LCD Display/Control Unit for Multi-Station System (Six Displays Max). Includes Installation Materials with 10 Meter Interconnect Cable

FAP5011A
$895.00

Optional 3.6" LCD Display/Control Unit for Multi-Station System (Six Displays Max). Includes Installation Materials with 10 Meter Interconnect Cable

FAP6821
$110.00
Remote Junction Box

Autopilot Pumps

Autopilot Pumps

PUMPHRP05-12
$810.00
0.5 CUBIC INCH P/SEC PUMP 12V (For Ram Sizes less than 8 Cubic Inches in Volume)
PUMPLA11-12
$2,750.00
LIN. ACTUATOR PUMP 9" RAM 12V
PUMPHRP17-24
$810.00

1.7 CUBIC INCH P/SEC PUMP 24V

PUMPHRP05-24
$810.00
24 0.5 CUBIC INCH P/SEC PUMP 24V (For Ram Sizes less than 8 Cubic Inches in Volume)
PUMPHRP11-12
$810.00

Autopilot Pump, 12 VDC, 1.1 Cubic Inches Per Second (For Ram Sizes of Up to 13 Cubic Inches in Volume)

PUMPHRP100-24
$1,350.00
0-3.5 CU IN/SEC ADJ PUMP 24V *
PUMPLA17-12
$2,380.00
Linear Actuator, 9" Ram,12V
PUMPHRP17-12
$810.00

Autopilot Pump, 12 VDC, 1.7 Cubic Inches Per Second (For Ram Sizes of 14 Cubic Inches to 25 Cubic Inches in Volume)

PUMPHRP11-24
$810.00

Autopilot Pump, 24 VDC, 1.1 Cubic Inches Per Second (For Ram Sizes of Up to 13 Cubic Inches in Volume)

PUMPHRP100-12
$1,350.00
0-3.5 CU IN/SEC ADJ PUMP 12V *

Miscellaneous Accessories

Miscellaneous Accessories

JAS-LC1-FFU
$1,200.00

Follow Up Lever Controller

MAG-COM-BKT
$50.00
Bulkhead Mounting Bracket (PG500R & PG1000)
100-306-531
$20.00
Display Snap-on Front Cover
JAS-JO1-NFU
$850.00
Non-Follow Up Lever Controller
000-147-017
$50.00
Termination Plug, FP64-01001 (Required Option if Connecting a Second Optional Display Directly to the Processor)
009-000-330
$75.00
Control Unit Mounting Bracket with Knobs

Manuals

Manuals

OME-725-00Z
$50.00
Operator's Manual, NavPilot 500
OSE-725-00Z
$7.00
Operator's Guide, NavPilot 500
IME-725-00Z
$40.00
Installation Manual, NavPilot 500
