FCV600

MSRP: $895.00

5.7" TruEcho CHIRP™ or CW Fish Finder

Display Size5.7 inches

Display TypeColor LCD

FrequencyCW 50-200kHz or CHIRP 40kHz to 225kHz

Power Usage12-24 VDC

Power Output600 W

Range1200 m

View Support/Tech Info Find a Dealer

All prices shown are in USD. Prices are valid in US and Canada only.

Home Products FCV600

Versatile Fish Finder for any vessel!

Furuno’s new stand-alone Fish Finders introduce all-new features that fishermen will love, built on the foundation of award-winning Furuno features that fishermen rely on. The 5.7” FCV600 can drive either a CHIRP or dual-frequency CW (Continuous Wave) transducer, allowing fishermen to configure the Fish Finder to suit their needs. Furuno’s TruEcho CHIRP™ delivers greater detail and target separation for baitfish, game fish, and structure by transmitting across a spectrum of frequencies.

Color Range Expansion shows you what you've been missing!

With the conventional color ranges, echoes from the seabed and a large fish are shown in a similar color, making it challenging to distinguish large fish from the bottom. With Color Range Expansion, the range of identifiable echoes is expanded so you can intuitively identify bottom fish from the seabed. Reefs, structure, and fish near the seabed are shown in slightly separated colors, making it easy to tell structure from fish at a glance.

Feature-packed Fish Finder with legendary Furuno quality

  • TruEcho CHIRP™- Operates across a wide range of frequencies using a broadband transducer for better signal clarity & target definition RezBoost™ Signal Processing - Improved clarity & resolution for conventional CW transducers
  • ACCU-FISH™ - A unique fish size and depth assessment function
  • Bottom Discrimination - Provides recognition of bottom composition with 4 types of graphic displays (Rock/Sand/Gravel/Mud)
  • NEW! Bottom Hardness Output - for external plotters such as TZ Professional and Olex (FCV800 only)
  • NEW! Color Expansion - Expands echo colors to easily identify fish from seabed
  • White Line Feature - Finds fish lying near the bottom by displaying the top edge of the bottom in white to clearly show bottom structure
  • Configurable Alarm Function - Depth, Fish echo, Speed, Arrival, and more!
  • TLL (Target Lat/Lon) Output - Interface with your Furuno Chart Plotter to mark fishing grounds with various information such as Depth, Water Temp, Fish Size, and Bottom Type (FCV800 only, requires a Chart Plotter)
  • Fast Transmission Rate- 3,000 PRR (Pulse Repetition Rate) per minute
  • NEW! Colors - Sunlight and Yellow color palettes
  • NEW! Wireless Connectivity – Wireless second display for simple installation
  • Cables
  • Single Band Chirp Transducers
  • 50 200 kHz Bottom Discrimination Transducers
  • Miscellaneous Accessories

Cables

Cables

$350.00
Transducer Extension Cable 02S4167-0
$89.00
12-Pin Transducer Extension Cable, 10 Meter
$50.00
NMEA2000 Micro Cable, 1 Meter, Male-Female connectors (straight)
$60.00
NMEA2000 Micro Cable, 2 Meter, Male-Female Connector
$80.00
NMEA2000 Micro Cable, 6 Meter, Male-Female Connector
$55.00
NMEA2000 Micro Cable, 1 Meter, Female Connector + Pigtail
$80.00
NMEA2000 Micro Cable, 2 Meter, Female Connector + Pigtail
$70.00
CBL NMEA2K MICRO-F 6M S-END

Single Band Chirp Transducers

Single Band Chirp Transducers

$475.00
Medium-Frequency CHIRP Transducer with Temperature - Bronze Thru-Hull, 300W
$350.00
Medium-Frequency CHIRP Transducer with Temperature - Plastic Transom Mount, 300W
$725.00
Low-Frequency CHIRP Transducer with Temperature - Bronze Thru-Hull, 300W
$750.00
Low-Frequency CHIRP Transducer with Temperature - Stainless Steel Thru-Hull, 300W
$750.00
Medium-Frequency CHIRP Transducer with Temperature - Bronze Thru-Hull, 600W
$750.00
Medium-Frequency CHIRP Transducer with Temperature - Stainless Steel Thru-Hull
$750.00
Medium-Frequency CHIRP Transducer with Temperature - Stainless Steel Thru-Hull with 12° Tilt
$750.00
Medium-Frequency CHIRP Transducer with Temperature - Stainless Steel Thru-Hull with 20° Tilt
$900.00
Medium-Frequency CHIRP Transducer with Temperature - Bronze Thru-Hull with High Speed Fairing Block
$750.00
High-Frequency CHIRP Transducer with Temperature - Bronze Thru-Hull
$750.00
High-Frequency CHIRP Transducer with Temperature - Stainless Steel Thru-Hull
$750.00
High-Frequency CHIRP Transducer with Temperature - Stainless Steel Thru-Hull with 12° Tilt
$750.00
High-Frequency CHIRP Transducer with Temperature - Stainless Steel Thru-Hull with 20° Tilt
$500.00
High-Frequency, Wide-Beam CHIRP Transducer - Plastic Transom Mount

50 200 kHz Bottom Discrimination Transducers

50 200 kHz Bottom Discrimination Transducers

$190.00

Plastic Thru-Hull Transducer, 600W (10-Pin)

$330.00

Bronze Thru-Hull Transducer, 600W (10-Pin)

$120.00

Plastic Transom Mount Transducer, 600W (10-Pin)

$195.00

Plastic Transom Mount Multisensor, 600W (10 Pin) ID
Airmar P66 Housing Style Transducer

$450.00

Bronze Thru-Hull Multisensor with High-Speed Fairing Block, 600W (10-Pin)
Airmar B744V Housing Style Transducer

$100.00

Plastic Thru-Hull, Low Profile, Transducer, 600W (10-Pin)

$120.00

Plastic Transom Mount Transducer with Temp, 600W (10-Pin)

$230.00

Bronze Thru-Hull Transducer with Temp, 600W (10-Pin)

$275.00

Bronze Thru-Hull Transducer with Temp, 600W (10-Pin), 12° Tilted Element

$275.00

Bronze Thru-Hull Transducer with Temp, 600W (10-Pin), 20° Tilted Element

$400.00

Stainless Steel Thru-Hull Transducer with Temp, 600W (10-Pin), 12° Tilted Element

$400.00

Stainless Steel Thru-Hull Transducer with Temp, 600W (10-Pin), 20° Tilted Element

Miscellaneous Accessories

Miscellaneous Accessories

$211.00
FLUSH MOUNT KIT OP02-89 FCV600
