Furuno Chart Radars Power Bridge Of Washington State Ferries' M/V Issaquah

Washington State Ferries maintains an unparalleled safety record, and their diligence can be attributed to professionalism, constant training, and reliance on the very best equipment available. The M/V Issaquah came up for an electronics update, and WSF turned to their long-time, trusted partner, Furuno, for the very latest in Navigation Electronics.

Camas, WA - Washington State Ferries is the largest ferry operator in the US and second largest in the world, running ten routes that serve 20 terminals around the Puget Sound and San Juan Islands. WSF maintains an unparalleled safety record, and their diligence can be attributed to professionalism, constant training, and reliance on the very best equipment available. The M/V Issaquah came up for an electronics update, and WSF turned to their long-time, trusted partner, Furuno, for the very latest in Navigation Electronics.

Built in 1979, Issaquah received a newly upgraded helm featuring four Furuno FAR3220NXTBB Chart Radars. These Black Box, Solid-State Chart Radars provide enhanced target detection with a refined user interface and new, aerodynamic antennas, as well as a host of new and improved features. The user interface of these advanced Chart Radars provides the operator with carefully organized tools, the Status bar and InstantAccess bar™, that deliver straightforward, task-based operation. Issaquah’s operators can quickly perform tasks without having to navigate an intricate menu tree, and access to all of the necessary functions is immediately available. With two Chart Radars on each end and enhanced side conning for added situational awareness, Issaquah is ready to carry on the WSF tradition of safe navigation for years to come.

Issaquah is the first WSF vessel with all-NXT Solid-State commercial Radars onboard, paired with the biggest and brightest monitors available, the MU270W. These widescreen monitors allow for 3-axis speed to be displayed directly on the Radar display, a feature that WSF pilots really appreciate. 3-Axis Speed displays important information for three different points of reference: Longitudinal Speed (ahead-astern), Transverse Speed (port-starboard) at the stern, and Transverse Speed (port-starboard) from a user-determined reference point. This information is critical in advising operators of the ship’s movement during challenging conditions, such as berthing.


“Having easy-to-see rate-of-turn and 3-axis speed at the conning position is a game changer. 3-axis speed gives me accurate fore-aft speed, and also transverse speed and stern speed. On other vessels, I have speed over ground, but I could be drifting and not actually know if I’m making forward progress towards the landing. With 3-axis speed, I know exactly how the vessel is behaving, especially in heavy current and strong wind. I also like the larger displays, which are easy to see peripherally, but are also out of the path of view through the windows.”

- Captain Joel Michelson, Washington State Ferries

Dual SC130 Satellite Compasses provide redundant heading and position, ensuring accurate heading from one end to the other. Issaquah is the first in the WSF fleet with completely redundant heading with automatic handover, ensuring continued data distribution if either antenna were to malfunction. If one compass were to fail, the other will take over automatically. With dual SC130 Satellite Compasses, the Issaquah has no need for a gyrocompass or the costly maintenance expenses they require.

“One of the most important things I noted about Issaquah’s installation was the fully redundant heading inputs to the navigation suite," said Captain Joel Michelson of WSF. "If a heading sensor antenna were to be lost at either end, the sensor from the opposite end seamlessly takes over, and all equipment continues to operate normally. In the past, loss of heading meant operating the Radars in heads-up only mode and doing without AIS or ARPA until the heading sensor was fixed. But on Issaquah, I’ll be momentarily alerted of the failure and still be able to navigate normally.”

Dual RD50 Remote Data Displays at each end take advantage of the fast heading, Rate-Of-Turn (ROT), and 3-axis speed information, and they’re fully adjustable thanks to custom RAM mounts that keep them at a perfect viewing angle for the operator without blocking the view outside the window.

´╗┐Coming from the largest fleet of ferries in the U.S., their continued reliance on Furuno at the heart of the operation is high praise for the Furuno product line. With the largest array of products in the marine electronics industry, Furuno has the perfect navigation solution for all workboat vessels, from tug boats and ferries to tankers and cruise ships.

Click Here for a guided video tour of the impressive new electronics suite aboard the M/V Issaquah. For more information on the FAR3000 Chart Radar series or any of their fine marine electronics, visit the Furuno website at www.FurunoUSA.com.

***
